Rectangular Lifting Magnet

Rectangular Lifting Magnet, Rectangular Lifting Magnet India, Lifting Magnet Manufacturers, Industrial Scrap Lifting Magnet

Rectangular Lifting Magnet

Rectangular Lifting Magnet For handling single layers of steel billets and rails in raft format, rectangular or bipolar lifting magnets are the ideal solution. The advantage of rectangular magnets is that the full – face width of the magnet can be utilized for lifting the billets and rails. This features aids handling and improves operational availability. Rectangular lifting magnets are also suitable for handling rafts of billets at temperature up to 600 C.

Rectangular Lifting Magnet
SUSPENDED ELECTROMAGNET

Suspended magnets are usually mounted above belt conveyor with the purpose of extracting pieces of tramp iron from the material being transported ranges incorporating electromagnets are available. The type chosen for particular application being determined by feed burden ,nature of tramp iron ,environmental condition and plant location.

CABLE REELING DRUM

SUSHIL’S Cable reeling drums are spring operated and gear operated which is essential accessories for lifting magnets in either mobile crane, E.O.T. crane, electrical hoists etc.

SPRING OPERATED drum revolves on a pair of ball bearings for smooth operation. The drum has a set of high tension springs on one side to reel and unreel drum and double contact slip-rings assembly for power supply to the magnet on the other side.
GEAR OPERATED drum revoves on a pair of ball bearings with help of gear, fitted on both relling drum and wire rope drum of crane.

SCRAP LIFTINF CIRCULAR ELECTROMAGNET
MODEL	DIA (MM.)	POWER (KW)	COIL	DUTY (%)	COLD CURRENT	HOT CURRENT	LIFTING CAPACITY IN KGS.
							SOLID	SPONGE	HEAVY MELTING	TURNING
SUSHIL’S 3A	300	1	AL	75	4	3	3000	100	120	40
SUSHIL’S 3C	300	1	CU	75	4	3	3000	100	120	40
SUSHIL’S 6A	600	2	AL	75	9	6	5000	150	150	60
SUSHIL’S 6C	600	2	CU	75	9	6	5000	150	150	60
SUSHIL’S 9A	900	4	AL	75	18	12	6000	180	200	75
SUSHIL’S 9C	900	4	CU	75	18	12	6000	180	200	75
SUSHIL’S 11A	1100	8	AL	75	36	25	10000	350	500	200
SUSHIL’S 11C	1100	8	CU	75	36	25	10000	350	500	200
SUSHIL’S 12A	1275	12	AL	75	54	38	12000	400	650	300
SUSHIL’S 12C	1275	12	CU	75	54	38	12000	400	650	300
SUSHIL’S 13A	1325	13	AL	75	59	41	14000	450	750	350
SUSHIL’S 13C	1325	13	CU	75	59	41	14000	450	750	350
SUSHIL’S 14A	1425	14	AL	75	63	44	16000	500	900	400
SUSHIL’S 14C	1425	14	CU	75	63	44	16000	500	900	400
SUSHIL’S 15A	1550	16	AL	75	72	50	20000	700	1050	500
SUSHIL’S 15C	1550	16	CU	75	72	50	20000	700	1050	500
SUSHIL’S 16A	1650	18	AL	75	82	57	27000	1000	1400	600
SUSHIL’S 16C	1650	18	CU	75	82	57	27000	1000	1400	600
SUSHIL’S 18A	1825	22	AL	75	100	70	30000	1200	1650	700
SUSHIL’S 18C	1825	22	CU	75	100	70	30000	1200	1650	700
SUSHIL’S 19A	1900	30	AL	75	136	95	36000	1400	1750	800
SUSHIL’S 19C	1900	30	CU	75	136	95	36000	1400	1750	800
SUSHIL’S 20A	2000	32	AL	75	145	101	38000	1600	1900	875
SUSHIL’S 20C	2000	32	CU	75	145	101	38000	1600	1900	875
SUSHIL’S 21A	2100	34	AL	75	154	108	40000	1800	2100	950
SUSHIL’S 21C	2100	34	CU	75	154	108	40000	1800	2100	950
SUSHIL’S 22A	2200	36	AL	75	163	114	50000	2000	2200	1050
SUSHIL’S 22C	2200	36	CU	75	163	114	50000	2000	2200	1050

BILLETS LIFTINF RECTANGULAR ELECTROMAGNET
MODEL	LENGTH (MM.)	WIDTH (MM.)	POWE R (KW)	COIL	DUTY	LIFTING CAPACITY OF BILLETS IN NUMBERS
						100 MM SQ	150 MM SQ.	180 MM SQ.	200 MM SQ.	SOLID (KGS)
SUSHIL’S 1590A	1500	900	6	AL	75	15	10	8	7	16000
SUSHIL’S 1590C	1500	900	6	CU	75	15	10	8	7	16000
SUSHIL’S 2190A	2100	900	9	AL	75	21	14	11	10	20000
SUSHIL’S 2190C	2100	900	9	CU	75	21	14	11	10	20000
SUSHIL’S 1770A	1700	700	7.5	AL	75	17	11	11	8	15000
SUSHIL’S 1770C	1700	700	7.5	CU	75	17	11	11	8	15000
SUSHIL’S 1155A	1100	550	5	AL	75	11	7	6	5	10000
SUSHIL’S 1155C	1100	550	5	CU	75	11	7	6	5	10000
SUSHIL’S 1445A	1400	450	5.5	AL	75	14	9	7	7	12000
SUSHIL’S 1445C	1400	450	5.5	CU	75	14	9	7	7	12000

N.B. – We are supplier of Elleptical electromagnets also as per customer requirements.

N.B. – All magnets are not suitable for every type of handling. The selection of a right magnet is very important. We offer our free service to customer to select a proper magnet for his industry.
